HHigh-Efficiency CD-Type Amorphous Inductor for Advanced Power Systems

Our CD-Type Amorphous Inductors utilize premium amorphous alloy core technology designed for next-generation power electronics that demand maximum energy conversion efficiency and ultimate power density. Featuring a split-core (CD-type) architecture, these inductors offer exceptional magnetic properties that far surpass traditional silicon steel and ferrite cores.

Engineered to handle high transient currents while maintaining ultra-low core losses and near-silent operation, they are the ideal choice for high-power PFC circuits, renewable energy, and automotive-grade applications.

Key Features

• • Extremely Low Core Loss: Amorphous alloy significantly reduces hysteresis and eddy current losses. This yields minimized heat generation and higher power conversion efficiency—delivering typically 80–90% lower core loss compared to traditional silicon steel.

  • High Saturation Flux Density:  Amorphous material offers a high saturation magnetic flux density (Bs ≈ 1.2-1.56T), which is 3-5 times higher than ferrite cores (0.3-0.5T). Allows the inductor to handle large transient currents without saturation, providing excellent reliability

  • Superior Miniaturization Capability: Thanks to high permeability and high Bs, the exact same inductance value can be achieved in just 1/8 to 1/10 of the physical volume of traditional inductors, enabling ultra-compact, high-power-density designs.

  • Low Noise & Low Vibration: Utilizing amorphous alloys with an extremely low magnetostriction coefficient, this design virtually eliminates audible core "squealing" or humming. This is a critical advantage for EV, audio, and medical applications.

  • Excellent Temperature Stability: High Curie temperature (up to 500°C+) ensures stable performance from -55°C to 130°C. Suitable for high-temperature, high-power environments

  • Adjustable Air Gap Flexibility: The CD-type split-core design allows for precise air gap adjustments, enabling customizable effective permeability to meet your exact circuit and ripple current requirements.

DC-Dias

Winding Specification

Material

Electrical Parameters

Target Applications

Our The ring-shaped powder core inductor are engineered for high-performance, high-power filtering and power factor correction:

• Switching Mode Power Supplies (SMPS) - Core Application

• E-Mobility: EV onboard chargers (OBC) & DC-DC converters.

• Industrial and Communication Power Supplies.High-Power Base Station Power Supplies and Server Power Supplies

• Power Quality: High-power PFC (Power Factor Correction) circuits and industrial switching power supplies.

Why Partner With Us？

• Proven Industry Expertise: With over 20 years of industrial experience and a solid foundation established in 2013, we operate five major core industrial lines across multiple specialized manufacturing bases to ensure top-tier product scale and stability.

• Global Quality Certifications: Our facilities strictly adhere to international automotive and industrial standards, backed by a complete set of major credentials including IATF16949, ISO9001, ISO14001, ISO45001, and ISO50001.

• Strong R&D & Technical Innovation: Driven by dedicated research teams and specialized new-design laboratories, we possess extensive patent portfolios and advanced testing capabilities to provide highly reliable, customized magnetic solutions.

• Smart & Scalable Manufacturing: We leverage advanced ERP and MES-managed smart manufacturing systems to optimize production capacity, securing a highly dependable supply chain for international clients across the EU, US, and globally.

FAQ

Q1: What are the main advantages of an amorphous core inductor?

A1: Compared to traditional silicon steel, amorphous cores cut energy losses by 80% to 90%, meaning much less heat generation. They also handle higher currents while being only a fraction of the size of standard inductors.

Q2: What is the benefit of the CD-type split-core design?

A2: The CD-type split-core design allows us to easily adjust the air gap. This flexibility means we can precisely customize the electrical performance to match your exact circuit and ripple current needs.

Q3: Will these inductors cause audible buzzing or noise?

A3: No. Our amorphous alloy material eliminates high-frequency core "squealing" or humming. This near-silent operation makes them ideal for noise-sensitive applications like electric vehicles (EVs) and audio systems.

Q4: Can I request customized specifications for my project?

A4: Yes, we provide full custom design services. We can adjust the inductance, current ratings, wire specs, and physical dimensions to ensure the component fits your specific power system requirements.
